Top Uses & Applications
High Volume Roll-to-Roll
Food & Snack
Print and finish labels inline
The DLP-2100 can print, die cut, and finish labels at up to 60 feet per minute. This full-featured workhorse is capable of laminating, die cutting, waste removal, slitting, and rewinding to finished rolls that are ready for application.
The label press is perfect for higher-volume label consumers as a way to bring label production in house to simplify inventory, reduce costs, and create flexibility. It’s best for situations involving repeat jobs and a small variety of predictable sizes.
Print shops are also using the DLP-2100 to offload short runs from larger, more expensive equipment or to add the capability to produce labels in-house—allowing for faster turnaround, better quality control, and more profitability on lower-volume label runs.
- Fast & affordable flexible steel dies
- Very fast finishing (≤ 12 IPS)
- Memjet-powered L901 included
- Best for repeat jobs, blank labels
Digital Label Press Details
The DLP-2100 is able to accommodate a massive roll of material (17.3 in/440 mm outside diameter), which drastically reduces stock cost from converters, and greatly simplifies operation by avoiding frequent roll changeovers.
A re-registering magnetic cylinder uses easily-swappable flexible steel dies that are low in cost and can be created quickly. These dies, combined with servo-controlled motors, allow for pinpoint cutting accuracy at high speeds, even with perforations. In addition to inline print applications, the DLP-2100 can be used to convert blank labels.
High output for large brands and print shops
With the L901 Digital Label Printer inline, the DLP-2100 can produce more than 25,000 full-color 3×4-inch labels per hour. For larger brands, this makes it ideal for bringing label production in house. Print shops can offload their smaller label runs, freeing up large format presses while reducing costs and setup times. Eliminating the need to outsource labels results in faster turnaround times, greater control and flexibility, and thousands of dollars saved.
The integrated L901’s print engine makes printhead maintenance possible with the web intact, allowing for uninterrupted production. In addition, it delivers industry-leading low ink costs via five (CMYKK) high-capacity cartridges.
≤60 ft/min. (18m)
|Print Quality:||1600 DPI full-color output|
|Max. Web Width:||9.65″ (245mm)|
|Lateral Paper Adjustment||0.5″ (12mm)|
|Core Sizes||3″ (76mm)|
|Max. Laminate OD||11″ (280mm)|
|Laminate||Economical, self-wound and supported laminate (on a liner). Liner removal included for use with high quality, liner-supported laminate|
|Max. Diecutting Width||9″ (230mm)|
|Max. Diecutting Length||12″ (304.8mm)|
|Cutting Dies||Flexible steel – Recommended total die length 7″ (177mm) to 12″ (304.8mm)|
|Registration Sensor Adjustment||Across web width|
|Sensor Mark||0.2″ x 0.2″ (5mm x 5mm)|
|Max. Finished Label Rewind||11″ (280mm)|
|Max. Waste Matrix Rewind||11.8″ (300mm)|
|Razor Slitter Assembly||6 knives|
|Razor Slitter Lateral Adjustment||0.47″ (12mm)|
|Media Capacity||Integrated unwinder, 19″ max outer diameter|
|Dimensions||88″ (223cm) W x 34″ (86cm) D x 57″ (145cm) H|
|Frame||0.4″ (10mm) solid aluminum|
|Safety||Emergency stop button|
|Loop||Photoelectric distance sensor|
|Power||240v AC, 10 A. (not adjustable)|
|Speed Control||Runs at 6″ or 12″/second|
|Motors||2, 400 W / 90 W|
|Control||PCB. Inverter, Encoder, Touchscreen control panel|
