The gist: Digitally cut labels of any shape and size without the need for dies. Laminate, cut, remove waste material, slit, and rewind labels to finished rolls, ready for application.
Top Uses & Applications
General Retail Labels
Health & Beauty
Seasonal & Market Testing
Cut any shape, without the need for dies
Plotter-style label finishing system
The Afinia Label Digital Label Finishers include all-in-one systems that unwind, laminate, digitally contour cut, remove waste, slit, and rewind in one simple process to create professionally finished labels. These solutions are perfect for on-demand, short-run label finishing from digital color label printers.
This full-size finisher is available in two widths (8.6 in/220 mm and 13.75 in/350 mm web widths) and with or without lamination capability.
Print shops are also using the DLF to offload short runs from larger, more expensive equipment or to add the capability to produce labels in-house—allowing for faster turnaround, better quality control, and more profitability on lower-volume label runs.
- Spacious paper path for ease of use
- Plotter-cut from a digital file (no dies)
- Ideal for short runs & proofing
- Cut any label shape easily
|Input / Output Roll Diameter||9.84” (250 mm)||9.84” (250 mm)|
|Minimum Web Width||4.33” (110 mm)||4.33” (110 mm)|
|Maximum Web Width||8.86” (225 mm)||14” (355 mm)|
|Maximum Cutting Width||7.87” (200 mm)||13” (330 mm)|
|Minimum Slitting Width||0.75” (19 mm)|
|Minimum Label Length||0.39” (10 mm)|
|Maximum Label Length||15” (381 mm)|
|Number of Slitting Blades||up to 8||up to 13|
|Minimum Media Thickness||0.01″ (0.25 mm) (10 mil)|
|Maximum Cutting Speed||24 in/s (600 mm/s) in all directions|
|Roll Core Size||3” (76 mm)|
|Agency Certifications||CE, FCC, RoHS|
|Warranty||One Year Parts and Labor. Usage Limitation may apply|
